17
LH 300/700 ILH300EN4
OPERATION – HATZ 1B30, MANUAL START
Max.
2
1
3
5 6
7
8
4
L000452
L000445
L000451
L000450
1. Open upper cover by pulling it forward.
2. Fill the fuel tank. Tank volume 5.0 lit. (5.3 qts)
Before start
Starting the engine
3. Check the engine oil level.
Oil volume 1.1 lit. (1.2 qts)
5. Pull the starting cable out by the handle until you
feel a slight resistance. Let the cable run back; in
this way the entire length of the starting cable can
be used to start the engine.
6. Grip the handle with both hands.
7. Begin pulling the starting cable vigorously and at
an increasing speed (do not jerk it violently) until
the engine starts.
If after several attempts at starting the exhaust
begins to emit white smoke, move the speed
control lever to the stop position and pull the
starting cable out slowly 5 times. Repeat the
starting procedure.
8. When you start the engine, leave it in
neutral a few minutes and warm up with
no load. The plate begins to move when
you apply hydraulic power by giving full
throttle.
4. Set the throttle in starting mode, indicated by the
forward position of the recess.
WARNING
CAUTION
