Rear panel controls and connections
Dynaudio Professional AIR reference manual – 2014-09-28 15
Slave/Sub – rear panel
1
23
Fig. 4: Slave/Sub – rear panel
1. RJ45 Link connections for downstream Slave units
2. Power input – 100 to 240 V
3. Power On/Off switch
Digital I/O card (optional)
Fig. 5: Digital I/O card (optional)
With this card installed in the option slot of the Master
unit, a 5.1 Digital/6 Master setup becomes an option.
Three AES/EBU connections (6 channels) can then be
fed to one Master monitor and distributed downstream.
For more information, see “Setups”.
