AIR setups
Dynaudio Professional AIR reference manual – 2014-09-28 43
Analog connections
►
The left input of the left monitor receives the left
signal.
►
The right input of the left monitor receives the left
surround signal.
►
The left input of the center monitor receives the
center signal.
►
The right input of the center monitor receives the
LFE signal.
►
The left input of the left surround monitor receives
the left surround signal.
►
The right input of the left surround monitor receives
the right surround signal.
►
The left input of the left inner monitor receives the
left inner signal.
►
The right input of the left inner monitor receives the
right inner signal.
