Placing the monitors
Dynaudio Professional AIR reference manual – 2014-09-28 49
This section of the manual is a guide to optimizing your
listening facilities to ensure optimal performance of
your AIR monitor system.
To ensure optimum results, it is essential that you have
connected all monitors in your AIR System properly.
Please refer to “AIR setups” on page 29.
For additional information on optimizing setups, in-
depth explanations and background information of vari-
ous acoustic phenomena, see “Appendix: Acoustics” on
page 106.
Overview
AngleDistance from listener
Left front-30°Minimum 1 m
Right front+30°Minimum 1 m
Centre0°Same distance as L or R front
1)
Left surround-110° ±10°Same distance as L or R front
2)
Right surround-110° ±10°Same distance as L or R front
2)
Notes:
1.) If you want to fulll the requirements of the ITU 775
standard, you should use one of the two approach-
es for position the center front monitor, along with a
Delay on the center monitor in order to achieve the
same time of arrival from all monitors.
2.) The delay time for each monitor can be adjusted
using the AIR Control software.
