OUTPUTS
Single Relay
Contact Type &
Rang: Single pole double throw (SPDT), latching or non-latching acon
(selectable); 2A resisve at 120/240VAC.
Lifeme: >500,000 operaons at rated voltage/current.
Isolaon: Basic Isolaon from universal input and SSR outputs.
Dual Relay
Contact Type &
Rang: Single pole single throw (SPST), latching or non-latching acon
(selectable); 2A resisve at 120/240VAC.
Lifeme: >200,000 operaons at rated voltage/current.
Isolaon: Reinforced safety isolaon from inputs and other outputs.
Linear DC
Accuracy: ±0.1% of span (mA @ 250Ω, V @ 2kΩ).
Resoluon: 15 3/4 bit (1 part in 52K) and updated at approx. 65ms intervals.
(130ms seling me)
Isolaon: Reinforced safety isolaon from inputs and other outputs.
Transmier PSU
Power Rang: 24V Tx PSU Module; Unregulated 18 to 32V DC into 400 Ω min
Linear Output Module; Regulated 0.0 to 10.0V into 500 Ω min.
Isolaon: Reinforced safety isolaon from inputs and other outputs.
SERIAL COMMUNICATIONS (RS485) (opon)
Physical: 1200, 2400, 4800, 9600 or 19200 bps.
Protocols: Selectable between Modbus and West ASCII.
Isolaon: Reinforced safety isolaon from all inputs and outputs.
OPERATING CONDITIONS (FOR INDOOR USE)
Ambient Temperature: 0°C to 55°C (Operang), –20°C to 80°C (Storage).
Relave Humidity: 20% to 95% non-condensing.
Altude <2000m
Supply Voltage and
Power: 100 to 240VAC 10%, 50/60Hz, 9VA
(for mains powered versions), or
20 to 48VAC 50/60Hz 9VA or 22 to 65VDC 5W
(for low voltage versions).
