Opon Module Connectors
Panel-Mounng
The mounng panel must be rigid, and
may be up to 6.0mm (0.25inch) thick.
Cut-out sizes are:
Cut-Out Dim A = 92mm
Cut-Out Dim B = 45mm
For n mulple instruments mounted
side-by-side, cut-out A is 96n-4mm
Tolerance +0.5, -0.0mm
