-23-
Selects the current test
conditions and displays the
t t t
Starts a test with the current
test
information and displays
the test status screen.
Displays the edit date
and time screen.
Sets the system volume to
the the maximum level.
Sets the system volume to
the medium level.
Sets the system volume to
the minimum level.
Sets the system volume to
Select/ OK button that will
accept the current condition.
Displays the tool tip
Logs the user in or displays
the Edit user window.
Displays the RTD calibration
Displays the LCD/
Display Calibration
id
