APPENDIX C—PNEUMATIC PACKER
Introduction
The packer accessory removes user variations on packing force. It applies a force that is
controlled by an air regulator. The packer is pivoted around to the barrel. It must be held in
place or it will return to its starting position. While the packer is held over the barrel, press its
switch to extend the packer end into the barrel. When the switch is released, the packer tip will
retract out of the barrel.
Activation and Operation
Press button to bring up the System Configuration screen.
Packer Air
Turn the Packer option from “OFF” to “ON” by pressing the white area around the word “OFF”
and then selecting the “ON” option that displays.
When activated or turned “ON” the Packer is available during test material loading times.
Option is only visible when the control cable for the packer is assembled onto the main board.
If the packer is used with the lift option, the lift will not lower unless the packer is back in its
starting position, outside of the unit’s working area.
