Dynisco LMI5000 Series - Instrument Overview; Front View; Rear View

From lab to production,
providing a window into the process
-16-
Lift System
Packer
Encoder
Auto Cutter
Power Switch
Power Cord
Figure 3: LMFI rear view Power connections
Instrument Overview
Front View
Figure 1: LMFI with lift, encoder and packer. (Cutter Location Shown)
Figure2: LMFI base unit (Encoder and Cutter Location Shown)
Rear View
