Dyon SMART 43 VX - Wall Assembly

EN
DYON SMART 43 VX
13
6.2 Wall assembly
Attach your wall bracket to the threads provided for this
purpose on the back and observe the hole spacing. You will
need two people for wall mounting. Please observe the
mounting instructions for the wall bracket used and the length
of the screws used.
Wall mount
Tool
Basis
Hole spacing
Screws
V7
C15
200*200
M6*9
