Dyson purifier hot+cool gen1 User Manual

Information menu
Filters
Indoor temperature
Particulate matter (PM2.5)
Particulate matter (PM10)
The remaining filter life is shown
on the LCD screen and will
indicate when your filters
need replacing.
Monitor the ambient temperature to help
maintain a comfortable environment.
Microscopic particles up to 2.5 microns in size,
suspended in the air we breathe. These include
smoke, bacteria and allergens.
Larger microscopic particles up to 10 microns
in size, suspended in the air we breathe. These
include dust, mould and pollen.
Indoor particulate matter – 12 seconds
Monitors the current particulate matter with a
graph showing the last 12 seconds of data.
Press this button to scroll through the information being monitored by your
Dyson purifying fan heater.
Information about particulate matter, temperature and filter levels is shown
on the LCD screen.
When a particular type of pollutant causes air quality to decrease,
a symbol for the pollutant will show on the LCD screen.
The remote control with
the information button
on the top right.

Dyson purifier hot+cool gen1 Specifications

General

Airflow	290 l/s
Cord length	1.8 m
Automatic mode	Yes
Air purify rate	- m³/h
Number of speeds	10
Oscillation angle	350 °
Air purifiers functions	Cooling, Heating
Noise level (low speed)	40 dB
Noise level (high speed)	63 dB
Timer duration (maximum)	8 h
Timer duration (minimum)	1 h
Suitable for room area up to	- m²
Package width	280 mm
Package height	823 mm
Package weight	7180 g
Battery type	CR2032L
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (max)	2362 W
Power consumption (standby)	1 W
Fine particle (PM2.5) numeric reading range	12 µg/m³
Display type	LED
Product color	White
Filter life (max)	12 month(s)

Weight and Dimensions

Depth	131 mm
Width	205 mm
Height	765 mm
Weight	5290 g
Remote control weight	25 g
Remote control dimensions (W x H x D)	32.2 x 10.49 x 101.9 mm
