E.C.A. CA 24 BB - Boiler Packaging

- BOILER PACKAGING
CAUTION: The instructions on the boiler package should be
considered during transportation and storage.
-The product is covered with a cardboard box of which dimensions are 867x522x422
(HxWxl) mm and supported by upper and lower styrofoams (fig. 2a).
a) b)
fig.2
- The required parts (Wall bracket, 5 pieces gasket for water and gas connections and
screews) for installation of the boiler is put into the upper styrofoam (fig. 2b). The other parts
which seen in the fig.2b are optional. The optional parts are:
a) Mounting
bracket
b) CH connecting pipes (3/4", 2 pieces)
c) DHW connecting pipes (1/2", 2 pieces)
d) Gas supply
pipe (3/4", 1 piece)
e) Nipples (1/2", 2 pieces- 3/4", 3 pieces) which are held with spring clips.
h) 4 pieces W gasket, 6 pieces %" gasket for water and gas connections.
