Swashplate Mixing (SWASH MIX)
AILE - 75%
ELEV - 75%
PITC + 85%
In the “Setup” list (SETUP LIST):
Servo Reversing (REVERSE)
AILE – R
RUDD – R
Swashplate Type (SWASH TYPE)
CCPM 120*
Timer (TIMER)
DOWN TIMER – 04:30
Spektrum DX7
In the “System Mode”:
Input Selection (INPUT SELECT)
GEAR = GYRO
Swashplate Type (SWASH TYPE)
3 SERVOS 120*
In the “Function Mode”:
Dual Rate and Exponential (D/R & EXP)
AILE
POS–1 POS-0
EXP + 15% EXP +20
D/R 80% D/R 100%
ELEV
POS–1 POS-0
EXP + 15% EXP +20%
D/R 80% D/R 100%
RUDD
POS-1 POS-0
EXP + 25% EXP +35%
D/R 70% D/R 100%
Note: These values serve only as starting points. It may be necessary to decrease or increase the
values per your preference.
Servo Reversing (REVERSING SW)
Ch 4 (RUDD) Reverse (REV.)
Ch 6 (PITC.) Reverse (REV.)
Travel Adjustment (TRAVEL ADJUST)
RUDD
L 90%
R 90%
Swashplate Mixing (SWASH MIX)
AILE + 65%
ELEV + 65%
PIT. + 80%
throttle hold (THRO HOLD)
ACT HOLD Pos.
HOLD SW 0.0%
Throttle Curves (THRO CURVE)
Point–L Point–1 Point–2 Point–3 Point–H
NORM 0.0% INH 50.0% INH 100.0%
ST–1 100.0% INH 85.0% INH 100.0%
ST–2 100.0% INH 100.0% INH 100.0%
Pitch Curves (PITCH CURVE)
Point–L Point–1 Point–2 Point–3 Point–H
NORM 35.0% INH 50.0% INH 100.0%
ST–1 0.0% INH 50.0% INH 100.0%
ST–2 0.0% INH 50.0% INH 100.0%
HOLD 35.0% INH 50.0% INH 100.0%
Note: In order to perform auto-rotations, it will be necessary to set the Point-L value for HOLD to
25.0% or less.
Gyro Sensitivity (GYRO SENS)
AUTO
RATE:
0: 70%
1: 70%
Note: These values serve only as starting points. It may be necessary to decrease or increase the
values in order to achieve the proper gain setting value.
Timer (TIMER)
DOWN–T
4:30
JR X9303 2.4
In the “System Mode” (SYSTEM M.):
Swashplate Type (SWASH TYP)
3servos
120*
In the “Function Mode” (FUNC. LIST):
Dual Rate and Exponential (D/R & EXP)
AILE POS-0 100% + 20%
100% + 20%
ELEV POS-0 100% + 20%
100% + 20%
RUDD POS-0 100% + 35%
100% + 35%
