E-Mon D-Mon Class 1000 - Main Power & Sensor Wiring Diagrams

Page 11
4.0 Meter Installation (Continued)
4.4 MAINS Line Voltage & Current Sensor Wiring Diagrams
∅
A
∅
B
∅
C
∅
A
W B N
Line Voltage Current Sensor
∅
A
N
1-Phase, 2-Wire Connection
120-Volt or 277-Volt Single-Phase
Line voltage connection: #14 AWG
Sensor Connection:
B = Black
W = White
* One-amp inline fuse recommended
Shorting link MUST be installed on
B- & C-phase current sensor
terminals.
LOAD SOURCE
∅
A
∅
B
∅
C
∅
A
∅
B
W B W B N
Line Voltage Current Sensors
∅
A
N
Single-Phase, 3-Wire Connection
120/240-Volt Single-Phase
Line voltage connection: #14 AWG
Sensor Connection:
B = Black
W = White
* One-amp inline fuses recommended
IMPORTANT: Line voltage MUST
be present at the A- & B-phase
voltage terminals.
Shorting link MUST be installed on
C-phase current sensor terminals.
∅
B
**
LOAD SOURCE
