EX4 Operation Manual
--- 2 ---
● Please use both hands to install the battery. Installing the battery with one hand may result
in poor battery installation.
TF Card Installation
The TF card slot is in the front of the bottom of the aircraft
body.
Before installing the TF card, open the TF card slot cover as
shown on the right picture, then insert the TF card into the
slot, and confirm that the TF card is in the right place, then
close the TF card slot cover.
● Please use micro SD card with transmission speed of
Class 10 and above or UHS-1 rating; maximum
support for 32GB capacity.
● Warning: Do not install or remove the TF card while the aircraft is powered on. Otherwise,
errors will occur for the data stored.
Aircraft Diagram
Counterclockwise Motor/ B
Propeller
Optical Flow Status Indicator
Clockwise Motor/A Propeller
To Next Page
