EACON EC5000 Series - Page 58

EC5000
- 106 -
- 107 -
MODBUS Communication Protocol
6
2101H Bit14~15
E=Reserved
IO Status Code
Bit0 S1
Bit1 S2
Bit2 S3
Bit3 S4
Bit4 S5
Bit5 S6
Bit6 S7
Bit7 S8
Bit8~9
Reserved
Bit10 Y1
Bit11 Y2
Bit12 Y3
Bit13 Y4
2102H
Bit14~15
Reserved
Running Status
Bit0 In Running
Bit1 Reversed Running
Bit2 AC motor driver ready
Bit3 Fault
Bit4 Inching Status
Bit5 Pre-Warning
Bit6~7 Reserved
Monitoring of
AC Drive Status
2103H
Bit8
Running Mode Bit0
Definition
Parameter
Word
Address
Function Description
Definition
Parameter
Word
Address
Function Description
0FH=EF2
010H=EF3
012H=EF4
013H=EF5
014H=EF6
015H=SP|
016H=Spo
017H=CE
018H=rr
019H=Rh
2100H
01AH=oPr
Pre-warning Code
Bit0
UuWarning
Bit1
ouWarning
Bit2
OH1Warning
Bit3
OL3Warning
Bit4
BBWarning
Bit5
EFWarning
Bit6
SERR Warning
Bit7
CALLWarning
Bit8 OH3
Bit9 CE
Bit10
OPE0
Bit11
OPE1
Monitoring of
AC Drive Status
2101H
Bit12
OPE2
EC5000
MODBUS Communication Protocol
