4.4.2 Communication,Objects,
No
Object Name
Function
Data Type
Flags
57
Operating Mode
Select Operating
Mode
1 byte
DPT 5.011
CW
Comfort mode
Enable
1 bit
DPT 1.003
CW
58
Night Mode
Enable
1 bit
DPT 1.003
CW
59
Away Mode
Enable
1 bit
DPT 1.003
CW
60
Protect Mode
Enable
1 bit
DPT 1.003
CW
“Operating Mode” is visible when “Switchover Comm Object Type” is “1 byte”. Values for enabling different
operating modes;
0: Comfort Mode, 1: Night Mode, 2: Away Mode, 3: Protect Mode.
“Comfort Mode”, “Night Mode”, “Away Mode” and “Protect Mode” are visible when “Switchover Comm
Object Type” is “4 bits”. Sending “True (1)” to this communication objects enables respective operating mode.
63
Switchover
Control Mode
Status
1 bit
DPT 1.100
CRT
Switchover
Control Mode
1 bit
DPT 1.100
CRWT
Switchover
Control Mode
Status
1 byte
DPT 20.105
CRT
Switchover
Control Mode
1 byte
DPT 20.105
CWRT
When “Switchover Type” is “Automatic” acts as a status communication object and sends current control
mode telegram from this communication object.
When “Switchover Type” is “Manual (via Object)” acts as a control communication object and current control
mode can be changed using this communication object.
74
Status Operating
Mode
Operating Mode
Status
1 byte
DPT 5.010
CRT
Status Comfort
Enabled
1 bit
DPT 1.002
CRT
75
Status Night
Enabled
1 bit
DPT 1.002
CRT
76
Status Away
Enabled
1 bit
DPT 1.002
CRT
77
Status Protect
Enabled
1 bit
DPT 1.002
CRT
