EAE ORIA - Product Introduction and Device Technology; General Product Overview; Device Technology, Data, and Dimensions

!
Product Manual Oria Thermostat
EAE KNX Oria Thermostat Oria Thermostat PM R1.0
©EAE!Technology!! ! ! ! www.eaetechnology.com!! ! ! Sayfa!4!/!50!
!!
!
!
1. General,,
Extendable!up!to!4!folds,!Oria!thermostats!offer!a!wide!range!of!functional!flexibility!with!integrated!
programmable!switches.!
Buttons!on!Oria!thermostats!can!be!programmed!to!control!lighting,!shutter/blind!drivers,!speak ers,!m ake!
scene!calls!and!mimic!panic!buttons.!Each!button!can!be!programmed!independently!for!a!different!function.!!
2. Device,Technology,
2.1 Button,Definitions,
!
!
!
!
1.!Programmable!Button!Group!1! !!!!!!!!!!!!2.!Fan!
Speed!(1,!2,!3,!A)! ! !!!!!!!!!!!3.!Operation!
Mode!(Comfort,!Night,!Away,!OFF)!4.!Setpoint!
Temperature!UP!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!5.!Setpoint!
Temperature!DOWN!!!!!!!!!!!!!!!!!!!!!!!!!!!6.!Programmable!
Button!Group!2!
!
!
!
2.2 Connection,Diagram,
!
!
!
!
1.!KNX!Port!Terminal!
2.!Programming!Button!
3.!Programming!LED!
!
!
!
!
