4.4.6.1,Parameter,
Parameter
Setting
Description
Comm Object Value to Enable
Automatic Fan Speed
0 / 1
Telegram value to enable
automatic fan speed might differ
between different actuators; use
this parameter to change the
telegram value for enabling
automatic fan speed.
Fan Speed Object Type
3 Bits / 1 byte
Selects the data type to control fan
speed.
4.4.6.2,Communication,Objects,
No
Object Name
Function
Data Type
Flags
66
Automatic Fan
Speed
Send
1 bit
DPT 1.002
CWT
Automatic fan speed will be enabled/disabled through this communication object. Telegram value to enable
automatic fan speed should be selected in “Comm Object Value to Enable Automatic Fan Speed” parameter.
67
Fan Speed
Send
1 byte
DPT 5.010
CWT
Fan Speed 1
Enable
1 bit
DPT 1.002
CWT
“Fan Speed” communication object visible when “Fan Speed Object Type” is “1 byte” and fan speed
controlled and status received with given values;
0 = Fan Speed 0, 1 = Fan Speed 1, 2 = Fan Speed 2, 3 = Fan Speed 3
“Fan Speed 1” communication object visible when “Fan Speed Object Type” is “3 bits” and sending “True”
telegram to this communication objects sets fan speed to fan speed 1.
68
Fan Speed 2
Enable
1 bit
SPT 1.002
CWT
“Fan Speed 2” communication object visible when “Fan Speed Object Type” is “3 bits” and sending “True”
telegram to this communication objects sets fan speed to fan speed 2.
Fan Speed 3
Enable
1 bit
DPT 1.002
CWT
“Fan Speed 3” communication object visible when “Fan Speed Object Type” is “3 bits” and sending “True”
telegram to this communication objects sets fan speed to fan speed 3.
,
!
!
!
!
!
!
