INSTALLATION
Wall Mounting Dimensions
7 5/8"
5 3/8"
ctr. to ctr. mounting holes
5 5/8"
ctr. to ctr. mounting holes
6 5/8"
3 3/16"
Enclosure conforms to: NEMA 4X
SPARE PARTS
1. INDICATOR CPU BOARD: EAGLE P/N 110267
2. INDICATOR DISPLAY BOARD: P/N 110266
EI2000 - O&M-v3.0
Revised 12/2/04
EI-2000
SPARE PARTS
EI-2000-DSP P/N = 110266
DSP1000 (EI-1000) = 110271
CPU P/N = 110394
EI-2000-IO = 110396
EI-2000-EXP = 110395
Interconnecting ribbon cable (8”) = 111026
