Eaglemaster LT-5200 - System Wiring Diagram

Redport
System wiring diagram
LED
Dual zone shock sensor
RED
BLACK
BLUE
GREEN
RED
BLAC K
BLUE
GREE N
+ 12v DC
- Ground
1st stage trigger
2nd stage trigger
CL-5180MAINCONTROL UNIT
Gray
Pink
Orange
Yellow
White/Black
Blue/White
Green/White
Purple
White
White/Red
White
Green/Black
Green
Green/Red
Blue/Black
Blue
Blue/Red
Red
Blown
Black
Valet switch
Central door
lock wiring
+ 12V DC
(-) Ground
Lock
Unlock
Left parking light
of direction indicator
Right parking light
of direction indicator
(-) Ground
Output to the (+) Siren
15A
10A
Lights(+)or (-)
input ,for the parking
lights power sources
ConnecttoChassis
Ground(-)
Connect to (+)
12Volts Battery
Sources
DOOR(+)
Connect to Existing (+)
Positive Door Switch
ConnecttoExisting(-)
NegativeDoorSwitch
Connect to (-) negative
trunk or hood pin switch
DOOR(-)
Connect (+)
12V Ignition
switch
(-) 500mA Channel
output for window close
(-) 500mA Channel
for 2nd eng kill
disarmed output
(-)500mA Channel
for Trunk open
(-) 500mA Channel
for Dome light output
External sensor port
" K4" on board
relay (40A)
for engine start
killer N/C type
30 - COM
87a - N/C
Antenna
Do not coil or around
the thin black Antenna
wire !!
30
87a
87
Built-in 40A
engine block relay
