15
PROBLEM CAUSE ACTION REQUIRED
The paint splatters Paint viscosity too thick Thin as required using appropriate thinners (see thinning instructions)
An area inside the spray gun has a degree of blockage Clean gun and filter paint in the container
Gun wasn’t correctly cleaned from previous project Clean gun
The paint drips or sags on
surface
Paint viscosity is low/thin Add undiluted paint
Paint output too high Reduce the paint output by scrolling Paint Flow Adjuster (8) downwards
Moving too slowly Increase speed of application
Spray trigger held too long Release trigger sooner
Spray gun too close Increase the distance between the spray gun and the work-piece
There is too much overspray
or fogging in the room
Paint flow too high and spraying too close to the
work-piece
Reduce paint flow and move further from the work-piece
No paint being released Paint too thick Add thinners
Fluid tip blocked Clean Fluid Tip (5)
Pick-up tube blocked or missing Clean the gun and the Rigid Pick-Up Tube (11) or insert Rigid Pick-Up Tube (11)
Air hose split Replace Air Hose (15)
Grainy paint Filter the paint
Paint container almost empty Refill Paint Pot (12)
Spray gun at an angle Check that the Rigid Pick-Up Tube (11) is pointing towards the paint
Air inlet blocked Check the condition of the Air Filter (21) and clean or replace as necessary
Troubleshooting &FAQ’s - Direct from the can or from the Paint Pot
ENSURE YOU REPLACE THE MATCHING FLUID TIP (Fig.25-5), NEEDLE (Fig.25-7), AIR CAP (Fig.25-3) AND SPRAY DIRECTION PLATE
(Fig.25-4).
● Unscrew Air Cap Ring (2).
● Remove Air Cap (3).
● Remove Spray Direction Plate (4).
● It is recommended to push the trigger forward to help release Fluid Tip (5).
● Using Needle and Fluid Tip Tool - pincher end A (1) remove Fluid Tip (5).
● Insert Needle and Fluid Tip end B (1) into the inner tube and unscrew the needle anticlockwise, then pull to release the needle.
● Insert the optional needle and screw into place.
● Insert the corresponding fluid tip and push into place.
● Reassemble all other parts in reverse order.
● Ensure Air Cap Ring (2) is fully tightened and Fluid Tip (5) is pushed into place so that the spray gun Needle (7) will shut off. Make sure the
Spray Direction Plate (4) is free to move. If necessary loosen Air Cap Ring (2) slightly.
Changing the Tip and Needle
Needle/ Fluid tip size Material sprayed
Tip HVACGEM10 - 1.0mm (0.04”) ultra fine finish tip
and needle kit
Acrylics, Synthetics, Polyurethane, Thinners, Lacquers, Oil-Based Stains
Tip HVACGEM15 - 1.5mm (0.06”) fine finish tip
and needle kit
Acrylics, Synthetics, Polyurethane, Thinners, Lacquers, Oil-Based Stains
Needle Selection Guidelines
Note: To use the 1mm and 1.5mm needles you will need to include the Standard V-gun Air Cap and Spray Pattern Adjuster.
