2.2 Front panel features
2.3 Rear panel features
a. 1kVAS & 1kVAH rear panel b. 2kVAS &2kVAH & 3kVAS & 3kVAH rear panel
① AC input socket ⑥ RS232 port
② Overcurrent protector ⑦ Intelligent slot
③ Fan ⑧ Surge protection for network / fax / modem
④ USB port ⑨ Output sockets
⑤ EPO (Emergency Power Off) port ⑩ Battery connector
Note:
The figure is for reference only. Due to the technology upgrading and development,
the real unit might be different from the figure.
