12
EASTMAN
ITEM PART NO. DESCRIPTION QTY.
34 PS-IL LInk, Pivot, L.H. 1
35 PM-84-2-MS Tube, Teardrop 2
36 344-34-4 Scr. Set Nylok Sokt.
1/4-20 x 1/4 2
37 *9141-046-012 Chain Assembly 1
PM-82 Screw Block, Long 1
PM-83 Screw Block, Short 1
38 *331-44-28 Scr. Cap Hex Hd.
1/2-20 x 1-3/4 2
39 *402-44 Washer, Lock, 1/2 2
40 *410-44 Washer, Flat 1/2 4
41 *410-010 Washer, Flat .#10 9
42 *335-99-10 Scr. Sokt. Cap Hd.
10-24 x 5/8 4
43 *332-99-8 Scr. Cap. Hd. Sokt.
10-24 x 1/2 3
44 *203-102 Nut, Hex 10-32 2
45 *542-6-5 Rivet, Flt. Hd. Solid 1
46 *410-010 Washer, Flat, (Modified) 4
47 *335-99-12 Scr. Sokt. Cap Hd.
10-24 x 3/4 1
48 *410-34 Washer, Flat 1/4 2
49 *335-34-10 Scr. Sokt. Cap Hd.
1/4-20 x 5/8 1
50 342-34-6 Scr. Set Sokt. Hd.
1/4-20 x 3/8 2
51 342-34-12 Scr. Set Sokt. Hd.
1/4-20 x 3/4 4
52 203-34 Nut, Hex 1/4-20 4
53 546-6-8 Pin 2
54 9002-001 Wsher, Flat 2
55 332-36-16 Scr. Cap Flthd. Sokt.
5/16-18 x 1 4
56 DY-1012 Finger, Pick Up Ass'y, Rear 1
57 DY-403 Finger, Pick Up, Rear 1
58 PM-03067-MS Teardrop Blade Ass'y 2
59 PM-11977 Retaining Clip 1
60 211-34 Nut, Elastic 1/4-20 2
61 PM-82 Stud 1
62 PM-83 Stud 1
MS- Machine Size
* Part of PM-0402
Front Frame Assembly, 9"
Please Specify machine voltage and
complete serial number when ordering
replacement parts.
Item numbers are for reference only. Please
Specify PART NUMBER when ordering replace-
ment parts.
ITEM PART NO. DESCRIPTION QTY.
1 CHT-424-3 Wheel, Hand, 5/8 Bore 1
2 V-68 Washer, Turbine 2
3 PM-76 Sprocket 1
4 PM-79 Bearing, Sprocket tube 1
5 PM-4-MS Shaft, Sprocket 1
PM-4-2-MS Shaft, Sprocket, Edge
Control, ONLY 1
6 *PC-1 Frame, Front, 9" 1
7 PM-77 Collar, Guide 1
8 PM-5-MS Tube, Sprocket, Shaft 1
9 *PM-11-1 Rod, Sliding, Short,
9" Machine 1
10 *PM-10-1 Rod, Sliding, Long,
9" Machine 1
11 *PM-0218 Wheel, Track Assembly
Pacemaker 2
12 *F-100 Bearing 2
13 *F-275 Ring for F-7 Wheel 1
14 *E-225 Washer, Steel 3
15 *F-7A Wheel, Track 1
16 *TL-221 Bushing, Track Wheel 1
17 *PM-25 Shaft, Connecting Bar 1
18 *PM-26 Bushing, Connecting Bar
Shaft 1
19 *PS-2 Plate, Fulcrum Support 1
20 *PM-27 Link, Counter Activating 1
21 *F-121 Sprocket 1
22 *PS-4 Bar, Actuating Counter 1
23 *PM-11465 Washer, Spring 1
24 *PM-29 Stud, Fulcrum Actuating 1
25 *PM-28 Stud, Fulcrum Pivot 1
26 *PS-3 Fulcrum, Counter 1
27 *PC-3 Block, Front Lifting 1
28 DY-1011 Finger, Pick Up Ass'y,
Front 1
29 PM-72 Bearing, Brake 2
30 DY-402 Finger, Pick Up, Front 1
31 PM-0101 Finger, Stud Assembly 2
32 PS-1 Link, Pivot R.H. 1
33 PM-0102 Stud, Pivot Link 2
From the library of: Diamond Needle Corp
