EASTMAN PACEMAKER - Front Upright Assembly

18
EASTMAN
Front Upright Assembly
Manual Edge Control
Item numbers are for reference only.
Please Specify PART NUMBER when
ordering replacement parts.
ITEM PART NO. DESCRIPTION QTY.
36 560-6-16 Pin, Roller 3
37 702-25 Chain, Link Connecting 4
38 203-34 Nut, Fin. Hex 1/4-20 2
39 331-36-12 Scr. Cap Hex Hd.
3/16-18 x 3/4 2
40 402-36 Washer Lock 5/16 2
41 335-34-40 Scr. Sokt. Cap Hd.
1/4-20 x 2-1/2 1
42 205-36 Nut Heavy Hex
5/16-18 2
43 335-99-12 Scr. Socket Cap Hd.
10-24 x 3/4 2
44 402-010 Washer Lock #10 2
45 410-010 Washer Flat #10 2
46 9120-604-1 Leather Brake Pad 2
47 531-2-8 Pin, Cotter 1
48 410-34 Washer, Flat 1/4 2
49 9004-0223 Spring Comp. Brake Adj. 1
50 632-18 Retaining Ring 1
51 A-253 Washer, Flat .502 ID
x .0299 Thk. 2
52 325-102-8 Scr. Mach. Phillips Jack
Hd. 10-32 x 1/2 2
53 9060-012 Collar, 1/2 ID 2
54 331-36-10 Scr. Cap Hex Hd.
5/16-18 x 5/8 2
* PS-29N Upright, Bottom Front, Lg. 1
(PM-0302-1 Upright #3 Only)
ITEM PART NO. DESCRIPTION QTY.
1 PS-11 Support, R.B.A. Roller R.H. 1
2 PM-54 Roller, R.B.A. Chain 3
3 PS-11L Support, R.B.A. Roller L.H. 1
4 PS-7 Bracket, R.B.A. Shaft 1
5 CEC-13 Roller, Guide 1
6 PS-9 Plate, R.B.A. Sliding 2
7 PM-50 Stud, R.B.A. Sliding Sleeve 2
8 PM-51 Stud, R.B.A. Sliding 2
9 PS-12 Plate, R.B.A. Chain
Mounting 2
10 PM-53 Spacer, R.B.A. 4
11 PM-55 Bearing 2
12 PM-52 Stud, R.B.A. Bearing 2
13 PS-6 Upright, Top Front 1
14 PS-8 Batwing, Front 1
15 PM-46 Stud, R.B.A. Stop 2
16 PM-56 Stud, R.B.A. Brake 2
17 *PS-30N Upright, Bottom Front
Med. Lg. 1
18 PS-10L Support, R.B.A. Double
Roller L.H. 1
19 PC-7 Bracket, Brake 2
20 PM-02200 Brake Adjustment Ass'y 1
21 PM-11390 Block, Brake Left 1
22 PM-11391 Block, Brake Right 1
23 PM-69 Nut, Brake Lock 1
24 PM-11392 Screw, Brake Adj. 1
25 PS-10 Support, R.B.A. Double
Roller R.H. 1
26 PM-58 Shaft, R.B.A. Actuating 1
27 M-52 Bearing, Flanged 2
28 CHT-424-2 Handwheel 2
29 PS-20 Support, R.B.A.
Actuating Shaft 2
30 PM-57 Actuating Sprocket 1
31 PM-63 Turnbuckle, R.B.A. Chain 1
32 PM-65 Screw, R.B.A. Chain L.H. 1
33 CH-58 Screw Chain 1
34 9140-020-002 Chain, Sprocket Ass'y 1
35 541-4-4 Rivet 6
