31
Expandabar
Spring Mechanisms Req'd.
-MS QTY.
42" 3
48" 3
54" 4
60" 4
66" 4
72" 5
84" 5
ITEM PART NO. DESCRIPTION QTY.
1 PM-1004-MS Expandbar 1
2 CHT-424-3 Handwheel 1
3 PM-114 Expanding Screw 1
4 PM-125 Washer 3
5 PM-111-MS Expanding Tube, Inside 1
6 PM-110-MS Expanding Tube, Outside 1
7 PM-0214 Expanding Collar,
Stationary 1 ea
8 PM-112-2 Expanding Collar, Long 1
9 PM-113 Expanding Collar, Short 1
10 PM-122 Expanding Spring, Collar 1 ea
11 PM-112-1 Expanding Collar, Long 1
12 PM-0215 Collar Assembly,
Movable 1 ea
13 PM-115 Expanding Spring 3 ea
14 PM-179 Extension Tube
(optional) 1
15 342-102-4 Scr. Soc. Hd. Set
10-32 x 1/4 2
16 342-102-2 Scr. Soc. Hd. Set
10-32 x 3/16 1
17 511-6-20 Roll Pin 1
18 511-6-14 Roll Pin 1
19 PM-118 Shifter 1
