EASTMAN PACEMAKER - Cross Member & Component Kit

16
EASTMAN
Cross member &
Component Kit
Item numbers are for reference only.
Please Specify PART NUMBER when
ordering replacement parts.
ITEM PART NO. DESCRIPTION QTY.
1 CHT-424-3 Wheel, Hand Bore 1
2 PM-77 Collar, Guide 1
3 PM-79 Bearing, Sprocket Tube 2
4 PM-5-MS Tube, Sprocket Shaft 1
5 PM-4-MS Shaft, Sprocket 1
6 PM-22-MS Platform 1
7 PM-0100-MS Staytube & Plug Ass'y 2
8 PM-11415 Plug, Nip Roller 2
9 F-122 Washer, Lower Rear
Elevating 2
10 PM-11394 Stud, Nip Roller 2
11 F-228 Bearing, Ball Flange 2
12 PM-8-MS Roller, Staytube 1
13 301-14-20 Scr. Wood Sltd. Flt. Hd.
14 x 1-1/4 4
14 342-102-3 Scr. Set Sokt. Hd.
10-32 x 3/16 1
15 331-44-32 Scr. Cap Hex Hd.
1/2-20 x 2 6
16 402-44 Washer, Lock 1/2 6
17 410-44 Washer, Flat 1/2 7
18 203-34 Nut, Hex 1/4-20 10
19 331-36-10 Scr. Cap Hex Hd.
5/16-18 x 5/8 4
20 402-36 Washer, Lock 5/16 10
21 331-36-16 Scr. Cap Hex Hd.
5/16-18 x 1 4
22 410-36 Washer, Flt. 5/16 10
23 F-185 Rod, Cross Short 2
24 F-183-A Turnbuckle 1/4-20 2
25 PM-2-MS Rod, Tie Long 2
26 9066-001 Tape, Poly A/R
MS-MachineSize
Heavy Duty KIT
ADD PM-6001-2-MS
PM-11445-MS Channel, Cross HD 2
PM-03065-MS Channel, Cross HD 2
PM-20743 Plate, End HD 4
SY-20295 Channel, Plate End 1
SY-20331-MS Channel, Cross Frame 2
SY-20330-MS Channel, Cross
Extrusion 2
PM-11401 Shim, Cross Channel 4
PM-0403-3 Frame, Back Ass'y HD 1
PM-0402-3 Frame, Front Ass'y HD 1
OMIT
PM-0402-1 Frame, 9" Front Ass'y 1
PM-0403 Frame, 9" Back Ass'y 1
PM-0402-2 Frame, 11" Front Ass'y 1
PM-0403-2 Frame, 11" Back Ass'y 1
F-183-A Turnbuckle 1/4-20 2
F-185 Rod, Tie Short 2
PM-2-MS Rod, Tie Long 2
PM-0100-MS Staytube & Plug Ass'y 2
