EASTMAN PACEMAKER - Back Frame Assembly

14
EASTMAN
Back Frame Assembly , 9"
Item numbers are for reference only. Please
Specify PART NUMBER when ordering replace-
ment parts.
Please Specify machine voltage and
complete serial number when ordering
replacement parts.
ITEM PART NO. DESCRIPTION QTY.
26 202-34 Nut, Hex 1/4-20 4
27 342-34-12 Scr. Set Sokt. Hd.
1/4-20 x 3/4
28 *411-48-2 Washer, Fiber .625 ID
x .0625 Thk. 1
29 *335-99-10 Scr. Sokt. Cap Hd.
10-24 x 5/8 4
30 *410-010 Washer, Flat #10 4
31 *410-44 Washer, Flat 1/2 6
32 *402-44 Washer, Lock 1/2 3
33 *205-44 Nut, Hvy Hex Jam 1/2-20 2
34 *9141-046-012 Chain Assembly, 9" 1
PM-82 Screw Block, Long 1
PM-83 Screw Block, Short 1
35 *206-44 Nut, Hex Fin. Jam 1/2-20 2
36 *411-44-2 Washer, Fiber
.500 ID x .062 Thk. 2
37 342-34-6 Scr. Set Sokt. Hd.
1/4-20 x 3/8 4
38 332-36-16 Scr. Cap Flthd. Sokt.
5/16-18 x 1 4
39 PM-03067-MS Teardrop Blade Assembly 2
MS-Machine Size
NOTE: All Pacemakers 84" and above require a
double track wheel configuration
(part number PM-02439).
ITEM PART NO. DESCRIPTION QTY.
1 *PC-2 Frame, Back 9" 1
2 *PM-76 Sprocket, Upper 1
3 *V-68 Washer, Turbine 2
4 *PM-12A Stud, Rubber Wheel 2
5 *PM-0205 Wheel, Rubber Ass'y 2
6 *PM-1000 Wheel, Rubber Modified 1
7 *TL-247 Bushing, Pillow Block Long 1
8 *PM-79 Bearing, Sprocket Tube 1
9 *PM-10-1 Rod, Sliding, Long 9"
Machine 1
10 *PM-11-1 Rod, Sliding, Short 9"
Machine 1
11 *PM-12 Stud, Sprocket Wheel 1
12 *F-121 Sprocket, Lower 1
13 *PC-4 Block, Back Lifting 1
14 DY-1012 Finger, Pick Up Ass'y, Rear 1
15 PM-72 Bearing, Brake 1
16 DY-403 Finger, Pick Up, Rear 1
17 PM-0101 Finger, Stud Assembly 2
18 PS-IL Link, Pivot, L.H. 1
19 PM-18 Stud, Pivot Link 2
20 PS-1 Link, Pivot, R.H. 1
21 PM-84-2-MS Tube, Teardrop 2
22 Dy-1011 Finger, Pick Up Ass'y
Front 1
23 DY-402 Finger, Pick Up Front 1
24 9002-001 Washer, Flat 2
25 546-6-8 Pin 2
