22
EASTMAN
ITEM PART NO. DESCRIPTION QTY.
29 342-34-4 Setscrew, 1/4-20 x 1/4 2
30 PEC-29 Cam 2
31 410-080 Washer, Flat #8 4
32 316-86-20 Screw, #8-32 x 1 1/4 4
33 11-1167 Switch Cover 2
34 11-1168 Limit Switch 2
35 CH-72 Nut Plate 2
36 410-36 Washer, Flat 5/16 2
37 331-36-16 Screw 1
38 331-36-20 Screw 1
39 PEC-25-A Cover, 20" Only 1
PEC-25-A Cover, 28" Only 1
PEC-25-A Cover, 34" Only 1
40 320-102-8 Screw, #10-32 x 1/2 3
41 PM-21521 Shaft, Auto Edge Control 1
42 601-404 Key 1
43 331-38-40 Screw, 3/8-16 x 2 1/2 2
44 205-38 Nut, Hex 3/8-16 2
45 402-38 Washer, Lock 3/8 2
46 410-38 Washer, Flat 3/8 2
47 211-34 Nut, Hex 1/4-20 3
48 332-34-8 Screw, 1/4-20 x 1/2 1
49 PM-30492 Mounting Plate 1
50 9059-027 Coupling 1
51 331-34-14 Screw, 1/4-20 x 1 1/8 3
52 11-6017 Motor, Edge Control 1
53 PM-12976 Spacer, Edge Upright 1
54 PM-57-2 Sprocket 1
55 601-403 Key 1
56 PM-13054 Spacer 2
ITEM PART NO. DESCRIPTION QTY.
1 335-99-6 Screw, Socket Hd.
#10-24 x 3/8 4
2 PM-30268 Cover, 220v Transformer 1
3 402-080 Washer, Lock #8 4
4 335-93-6 Screw, Socket Hd.
#8-32 x 3/8 4
5 410-080 Washer, Flat #8 4
6 11-994-1 220v Transformer 1
7 PM-2007 Plate, Transformer 1
8 PM-21520 Cover, 110 volt Only 1
9 PM-12933 Bracket 1
10 410-36 Washer, Flat 5/16 1
11 216-36 Nut, Lock 5/16 1
12 9143-001 Reflector 2
13 PM-12930 Reflector Plate 1
14 332-86-6 Screw #6-32 x 3/8 4
15 PM-30528 Reflector Bracket 1
16 335-99-6 Screw, Socket Hd.
#10-24 x 3/8 1
17 PM-21516 Reflector Mount 1
18 PM-20828 Bottom Cover 1
19 206-39 Nut, Hex 3/8-24 1
20 TL-238-2 Handle 1
21 332-102-8 Screw #10-32 x 1/2 2
22 410-34 Washer, Flat 1/4 3
23 402-34 Washer, Lock 1/4 3
24 331-34-10 Screw, 1/4-20 x 5/8 3
25 378-86-4 Screw 4
26 211-102 Nut, Elastic #10-32 2
27 PM-21522 Plate, Control Box 1
28 11-3312 Control Box 1
Edge Control
Assembly
