EASTMAN PACEMAKER - Page 36

36
EASTMAN
Movable Catcher Assembly
ITEM PART NO. DESCRIPTION QTY.
1 CHT-1140 Bumper, Catcher
(part of PM-0406) 2
2 PM-96-MS Bar, 3/4" Dia. 1
3 PM-95-MS Rod, Tie, Catcher 2
4 PM-0406-MS Bar, Pin Assembly 1
5 PM-1005 Shim, Bracket 2
6 PM-97-MS Bar, Pin 1
7 PM-98-MS Bar, Stripper 1
8 PM-120-MS Matting, Corrugated Rubber 1
9 PM-91 Spring, Catcher A/R
10 PM-121 Stud, Stripper Bar A/R
11 332-38-16 Scr. Cap Flthd. Sokt.
3/8-16 x 1 4
12 335-102-8 Scr. Sokt. Cap Hd.
10-32 x 1/2 2
13 402-010 Washer, Lock #10 2
14 410-010 Washer, Flat #10 2
15 332-102-10 Scr. Cap Flthd. Sokt.
10-32 x 5/8 6
16 332-102--8 Scr. Cap Flthd. Sokt.
10-32 x 1/2 6
17 F-218 C-Clamps 2
