Chapter 1. Product Overview
1.1 Product Introduction
The SDM320C is a single phase multi-function remote control energy meter. It measures all important
electrical parameters, such as Active Energy (kWh), Current (A), Voltage (V), Frequency(Hz), Power Factor,
Power Demand, import and export energy etc. With built-in relay inside, the meter can be remotely
controlled to turn on or off the electricity supply via RS485. The user can also set alarm objects and alarm
level, once the alarm is activated the relay will be turned off automatically.
1.2 Product Feature
 Max.100A Direct Connect
 Multifunction Measurement, Displays Scroll Settings
 Support AMR, SCADA system
 Remote Control with Bulit-in Relay
 Energy Resettable
 White Backlit LCD Display
 Din Rail Mounting 35mm
1.3 Application Scenarios
The SDM320C is suitable for scenarios where remote control switches are required.
Chapter 2. Technical Specification
2.1 Technical Parameters
Input Voltage
Basic Voltage (Un):
230V AC L-N, 120V AC L-N
Operating Voltage Range:
±20% of Un
Measurement Form:
RMS
Input Current
Basic Current (Ib/ Iref):
5A
Max. current(Imax.):
100A
Over Current Withstand:
20 Imax for 0.5s
Input Frequency
45-65 Hz
Insulation Capabilities
AC voltage withstand:
4KV/1min
Impulse Voltage Withstand:
6kV – 1.2µS waveform
Power Consumption
≤ 2W
Pulse Port：
Can be Set（See Operating Instructions for
Details）
Pulse Output Rate
1000imp/kWh(Default)
Display
LCD with White Backlit
Max reading
999999.99 kWh
