EasyIO FS32 User Manual

EasyIO FS32 – User Reference v1.4
9
Digital Output Wiring Connection
EasyIO FS Series digital output is for general purpose isolated digital output connections (relay output).
 24 VAC , 2.0A 
 24 VDC , 2.0A 
Digital Output
8 Channels (FS-32) , 2 Channels (FS-20)
Type
Relay Contacts, SPST NO, 48VA at 24VAC,
It does not output voltage or current. It is a dry relay contact.
Digital Output Connection

EasyIO FS32 Specifications

General

Brand	EasyIO
Model	FS32
Category	Controller
Language	English
