Eaton 9PX - Model Specific Data (Continued)

Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02 43
Table 12. Electrical Output (Continued)
All Models Normal Mode Efficiency Mode Battery Mode
>130% :2s
>150% : shutdown after 300 ms
Overload warning then transfer to stop output
Output Overload ( Bypass
Mode )
102%~110% :Overload warning
110%~130% :shutdown after 5mins
130%~150% :shutdown after 15s
>150% :shutdown after 300ms
Percent is based on nominal current in bypass mode
Voltage Waveform Sinewave
Harmonic Distortion
< 3% THDV on linear load
< 5% THDV on non-linear load
Transfer Time Online Mode: 0ms
High Efficiency mode: 10ms maximum (due to loss of utility)
Power Factor Up to 1.0
Load Crest Ratio Up to 3:1
Table 13. Electrical Output Connections
Model Output Connection Output Cable
9PX1500IRT2U-L
(4) IEC10A
(2) IEC10A group 1
(2) IEC10A group 2
(2) IEC10A
9PX2200IRT2U-L
(4) IEC10A + (1) IEC16A
(2) IEC10A + (1) IEC16A group 1
(2) IEC10A group 2
(2) IEC 10A
9PX3000IRT2U-L
Table 14. Environmental and Safety
Certifications
IEC/EN 62040-1
IEC/EN 62040-2 : Cat. C1
IEC/EN 62040-3
UL1778 5th edition
CSA 22.2
EMC ( Emissions)*
CISPR22 Class B
FCC part 15 Class B / ICES-003
EMC (Immunity)*
IEC 61000-4-2, (ESD): 8 kV Contact Discharge / 15 kV Air
Discharge
IEC 61000-4-3, (Radiated field): 10 V/m
IEC 61000-4-4, (EFT): Power (Coupling network) 4 kV / Ethernet
(Coupling
clamp) 2 kV
IEC 61000-4-5, (Surges): 2 kV Differentiel Mode / 4 kV Common
Mode /
Model Specifications
