Eaton EX RT 11 User Manual

Page 14 - 34007724EN/AD
Follow steps 1 to 4 for rack mounting the UPS onto the rails.
The rails and the necessary mounting hardware are supplied by EATON.
Note for step 1: it is possible to adjust the position of both front mounting ears.
1
3
3
4
2
1
4
3
3
Power or battery module rack mounting (optional rails required, part number: 68001)
2. Installation
5
6

Eaton EX RT 11 Specifications

General

Model	EX RT 11
Form Factor	Rack/Tower
Topology	Double Conversion Online
Output Power Factor	0.9
Frequency	50/60 Hz
Power Rating	11 kVA / 9.9 kW
Efficiency	Up to 95%
Battery Type	Sealed Lead Acid
Communication	USB, Serial
Expandability	Yes
Operating Temperature	0 to 40 °C
