Eaton MMX12AA1D7F0-0 - Door Keypad Dimensions

Appendix B
184 M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com
Approximate Dimensions in inches (mm)
Door Keypad Dimensions
0.87
(22.0)
0.71
(18.0)
3.94
(100.2)
2.26
(57.4)
2.77 (70.3)
4.92 (125.0)
Front View Side View
