M-Max Series Overview
12 M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com
Power Connection Voltages, continued
Notes
Rated motor currents for normal four-pole internally-cooled and surface-cooled three-phase asynchronous motors
(1500 min
–1
at 50 Hz, 1800 min
–1
at 60 Hz).
Calculated motor output (no standard value).
Operation with reduced load torque (about –10% M
N
).
Allocated motor output at a maximum ambient temperature of 104°F (40°C) and a maximum pulse frequency of 4 kHz.
Part Number
Rated
Current
Overload
Current
(150%) Assigned Motor Rating
Frame Size
I
e
I
150
P
(400V, 50 Hz)
P
(460V, 60 Hz)
(A) (A) (kW) (A)
(hp) (A)
3 AC 400V, 50/60 Hz
(323–528V ±0%, 45–66 Hz ±0%)
MMX34AA1D3_ 1.3 2 0.37 1.1 1/2 1.1 FS1
MMX34AA1D9_ 1.9 2.9 0.55 1.5 3/4 1.6 FS1
MMX34AA2D4_ 2.4 3.6 0.75 1.9 1 2.1 FS1
MMX34AA3D3_ 3.3 5 1.1 2.6 1-1/2 3 FS2
MMX34AA4D3_ 4.3 6.5 1.5 3.6 2 3.4 FS2
MMX34AA5D6_ 5.6 8.4 2.2 5 3 4.8 FS2
MMX34AA7D6_ 7.6 11.4 3 6.6 4
6.4
FS3
MMX34AA9D0_ 9 13.5 4 8.5 5 7.6 FS3
MMX34AA012_ 12 18 5.5 11.3 7-1/2 11 FS3
MMX34AA014_ 14 21 7.5
15.2
10
14 FS3
MMX34AA016_ 16 24 7.5 15.2 10 14 FS4
MMX34AA023_ 23 34.5 11 21.7 15 21 FS4
MMX34AA031_ 31 46.5 15 29.3 20 27 FS5
MMX34AA038_ 38 57 18.5 36 25 34 FS5
3 AC 575V, 50/60 Hz
(489–632.5V ±0%, 45–66 Hz ±0%)
MMX35AA1D7_ 1.7 2.6 0.75 1.7 1 1.7 FS3
MMX35AA2D7_ 2.7 4 1.5 2.7 2 2.7 FS3
MMX35AA3D9_ 3.9 5.9 2.2 3.9 3 3.9 FS3
MMX35AA6D1_ 6.1 9.2 4 6.1 5 6.1 FS3
MMX35AA9D0_ 9.0 13.5 5.5 9.0 7.5 9.0 FS3
