Appendix
Special technical data
The following tables show the technical data of the frequency
inverter M-Max
TM
 in the individual power classes with the
allocated motor output.
Device series MMX11
h
The motor output allocation is based on the rated
operational current.
h
The motor output designates the respective active power
output to the drive shaft of a normal, four pole, internally
or externally ventilated three-phase asynchronous motor
with 1.500 rpm at 50 Hz or 1.800 rpm at 60 Hz.
MMX11 Symbols
used in
technical
data and
formulae
Unit 1D7 2D4 2D8 3D7 4D8
Rated operational current  I
e
A 1.7 2.4 2.8 3.7 4.8
Overload current for 60 s every 600 s
at 50 °C
I
L
A 2.6 3.6 4.2 5.6 7.2
Starting current for 2 s every 20 s
at 50 °C
I
L
A 3.4 4.8 5.6 7.4 9.6
Apparent power at rated operation
1)
230 V S kVA 0.68 0.96 1.12 1.47 1.91
240 V S kVA 0.71 0.99 1.16 1.54 1.99
Assigned motor rating (230 V)
1)
PkWh0.25 0.37 0.55 0.75 1.1
HP 1/3
2)
1/2 1/2 3/4 1
Power side (primary side):
 Number of phases single-phase or two-phase
Rated voltage

U
LN
1)
V 110 - 15 % - 120 + 10 %, 50/60 Hz
(94 - 132 V ±0 %, 45 - 66 Hz ±0 %)
 Input current I
LN
A 9.2 11.6 12.4 15 16.5
Maximum leakage current to ground (PE)
without motor
MMX11...N... I
PE
mA
Braking torque
 Default M/M
N
% F 30
DC braking I/I
e
% F 100, adjustable
Pulse frequency f
PWM
kHz 6 (adjustable 1 – 16)
Heat dissipation at rated operational
current (I
e
)
P
v
W 22.3 27.9 33.4 40.3 49.2
Efficiency h 0.91 0.92 0.94 0.95 0.96
Fan (device-internal, temperature-
controlled)
/ / / / /
Installation size FS2 FS2 FS2 FS2 FS3
Weight m kg 0.7 0.7 0.7 0.7 0.99
1) Internal voltage doubler circuit
U
LN
=115V a U
2
= 230 V
U
LN
=120V a U
2
= 240 V
2) Guide value (calculated), no standard rating
