DMI
28
11/04 MN01219002Z-EN
Data interrogation The following types of data can be called up in the DMI:
• Process data supplied by the circuit-breaker,
• Parameter settings,
• Identification data of the circuit-breaker and any fitted
modules,
• Status messages from the circuit-breaker,
• Status messages from the DMI.
Data can be interrogated in two different ways:
• Constantly required data can be incorporated in the
standard display and called there continuously,
• If necessary, less frequently required data can be called in
the Display menu or in the status menus.
Display menu
You can also use the Display menu to include important data
in the standard display (a section “The standard display”,
Page 33).
If necessary, less frequently required data can be
interrogated via the Display menu.
X In the main menu use cursor buttons Í or Ú to select
Display menu.
X Confirm your selection by pressing OK.
X Select the submenu you require using the cursor buttons
Í or Ú.
X Confirm your selection by pressing OK.
