FIELD INSTALLED UPM INSTALLATION PLAN AND UNPACKING
EATON 9395 Field Installed UPM Mechanical Installation Manual S 164201717 Rev 3 www.eaton.com/powerquality
3−2
The FI−UPM operating environment must meet the weight requirements shown in
Table 3-1 and the size requirements shown in Figure 3-1 through Figure 3-6.
Dimensions are in millimeters (inches).
Table 3-1. FI−UPM Cabinet Weight
Model
Weight
kg (lb)
Shipping Installed
Eaton 9395 FI−UPM 642 (1415.4) 606 (1336)
The FI−UPM cabinet uses forced air cooling to regulate internal component
temperature. Air inlets are in the front of the cabinet and outlets are in the top. Allow
clearance in front of and above each cabinet for proper air circulation. The clearances
required around the FI−UPM cabinet are shown in Table 3-2.
Table 3-2. FI−UPM Cabinet Clearances
From Top of Cabinet 457.2 mm (18") minimum clearance for ventilation
From Front of Cabinet 914.4 mm (36") working space
From Back of Cabinet None Required
From Right Side of Cabinet None Required
From Left Side of Cabinet None Required
The basic environmental requirements for operation of the FI−UPM are:
S Ambient Temperature Range: 0–40°C (32–104°F)
S Recommended Operating Range: 20–25°C (68–77°F)
S Maximum Relative Humidity: 95%, noncondensing
The FI−UPM ventilation requirements are shown in Table 3-3.
Table 3-3. FI−UPM Air Conditioning or Ventilation Requirements During Full Load Operation
Rating Input/Output Voltage
Heat Rejection
BTU/hr 1000 (kg−cal/hr)
Ventilation Required for
Cooling Air Exhaust
225 kVA
400/400 43 (10943)
Approximately
755 liter/sec
(1600 cfm)
480/480 44 (11054)
275 kVA
400/400 53 (13375)
480/480 54 (13510)
300 kVA
400/400 51 (12969)
480/480 51 (12969)
