2. 600 WIDE EXPLODED VIEW
ITEM DESCRIPTION
1 Steel door assy option
2 Glass door assy option
3 Vented door assy option
4 Side panel
5
6
7
Steel door supplied with vented front door
Vented door supplied with glass/steel front door
Enclosure frame
RE Series Enclosure Installaon Guide Issue 8
