5. STABILIZING
Caution; Before the rack is configured with equipment (if the combined weight of
the rack and equipment is over 200kg) THE FOLLOWING PROCEDURE MUST BE
IMPLEMENTED AND THE RACK MUST REMAIN STATIC. If the rack is to be relocat-
ed then equipment MUST be removed before moving the rack.
Each enclosure is equipped with four leveling feet (Fig 1).
Use a 13 mm spanner to adjust the leveling feet. Ensure that each foot is in firm contact
with the floor. Using a level, adjust the leveling feet as required to level the enclosure. For
enclosures that have casters, extend the leveling feet so that the casters are
approximately 3 mm off the floor.
RE Series Enclosure Installaon Guide Issue 8
