3. 800 WIDE EXPLODED VIEW
ITEM DESCRIPTION
1 Steel door assy option
2 Double Vented door assy option
3 Glass door assy option
4 Vented door assy option
5
6
7
8
Side panel
Steel door supplied with vented/double front door
Double vented door supplied with glass/steel front door
Enclosure frame
RE Series Enclosure Installaon Guide Issue 8
