Eaton Vickers DF3S4-16 Series User Manual

43
Figure 26a. DG5S4-10**-53/54 Internal Pressure Passages & Plug Locations
Plug Installation Table
Model
“C”
Plug
“B”
Plug
“A”
Plug
DG5S4-10**-53
DG5S4-10**-E-53
DG5S4-10**-X-53
DG5S4-10**-X-E-53
*In
In
Out
In
Out
*In
* - Denotes Orifice Plug
B
P
T
A
T
“C” Plug
Does
not
Exist
Out
“B” Plug
“X” Port
Figure 26b. DG5S4-10**-(K/R/S)-53 Internal Pressure Passages & Plug Locations
Plug Installation Table
Model
“C”
Plug
“B”
Plug
“A”
Plug
DG5S4-10**-K/R/S-53
DG5S4-10**-E-K/R/S-53
DG5S4-10**-X-K/R/S-53
DG5S4-10**-X-E-K/R/S-53
*In
In
Out
In
Out
*In
* - Denotes Orifice Plug
B
P
T
A
T
“C” Plug
In
Out
“B” Plug
“X” Port
Integral Check Valve
“A” Plug
