Eaton Vickers DG3V-8 Series User Manual

5
Model Code (continued)
20
18
21
17
28
16
Solenoid Energization Identity
Blank - Standard arrangement for ANSI
B93.9 (i.e. energize solenoid A to
follow flow P to A).
V - Solenoid identification determined
by position of solenoid (i.e. solenoid A
at port A end/solenoid B at port B end).
Note
4 and 8 type spools are always V.
Solenoid energization identity is
independent of mainstage porting.
Heading Electrical Flag Symbol
M - Features and options for pilot valve.
Pilot Valve Monitoring Switch
(Omit if not required)
S3- Limit switch normally open, wired to
electrical connector with AC w/PA5
(H piloted models only)
S4- Limit switch normally closed, wired
to electrical connector with AC w//PA5
(H piloted models only)
S5- Limit switch - unwired
(H piloted models only)
S6- Position switch with DC w/U coils
(H piloted models only)
Coil Type
F - Flying lead (required for wiring
housing option)
KU - Top exit flying lead
P - Plug in
SP1- Single 6.3mm spade
SP2- Dual 6.3mm spade
U - ISO 4400 (DIN 43650)
X1 - Flameproof solenoids
BASEEFA/CENELEC
(S piloted models only)
X2 - Explosion proof solenoids CSA/UL
(S piloted models only)
X3 - Explosion proof solenoids
BASEEFA ExS
(S piloted models only)
Electrical Connections
(F type coils only, omit if not required)
PA - Insta–plug, male receptacle only
PB - Insta–plug, male and female
receptacle
PA3-3–pin connector
PA5-5–pin connector
T - Wired terminal block (wiring
housing option also required)
Wiring Housing
W - 1/2” NPT threaded connection
J - 20mm threaded connection
G - 1/2” BSPP threaded connection
Electrical Options
(Omit if not required)
U-type coils only
1- Fitted connector
2- Fitted connector and variable
grommet
6- Fitted connector with lights
Solenoid Indicator Lights
(Omit if not required)
Surge Suppressor/Damper
(DC voltages only, omit if not required)
D1- Encapsulated diode (industrial
applications)
D2- Encapsulated diode (mobile
applications)
D7- Encapsulated transzorb
Coil Voltage Identification Letter
Pilot Valve Port Orifices
(Omit if not required)
Design Number
Special Modifications
(Omit if not required)
22
25
26
23
24
27
19
16 17 18 19 2620 21
22 23 24 25
27
28
