3. TECHNICAL DATA
3.1 Product drawing
All measures have the unit mm.
1 Direction of air flow "V"
2 Tightening torque 0.5±0.1 Nm
3 Cable diameter max. 7.5 mm; tightening torque 1.3 ± 0.2 Nm
