#3SelectionMenu
PressMenuSelect
Downbutton

#4 ChooseSetupMenu
ToinitiatetheSetupMenu
Simultaneouslypressboth
HorizontalCALIBRATEkeys


#5DefinePlot
(GraphicalDisplay)
PressMenuSelect
Downbutton

#6SampleRate
(GraphicalDisplay)
PressMenuSelect
Downbutton


#7OutputRange
4mAvalue
Toinitiatethe4mAvalue
Simultaneouslypressboth
HorizontalCALIBRATEkeys

#8Adjusting4mAvalue
Factorysettingis0.00ppm
Anyvaluecanbeentered
usingtheCALIBRATEkeys
PresstheMenuSelect
downkeytoacceptthe
value


#9OutputRange
20mAvalue
PressMenuSelect
Downbutton

#10Adjusting20mA
value
Toinitiatethe20mAvalue
Simultaneouslypressboth
HorizontalCALIBRATEkeys


#11Adjusting20mAvalue
Selectthedigittochange
withthehorizontal
CALIBRATEkey

#12Adjusting20mA
value
Adjustthevaluewiththe
VerticalCALIBRATEkeys


#13AcceptingtheValue
Acceptthe20mAvalueby
PressingtheMenuSelect
Downkey

#14ReturntoHome
Screen
ToreturntotheHome
Screen
PresstheCALIBRATEDown
Key.



