FCA‐22InstructionManual




Page14



AlarmRelays
TheFCA‐22hastwoassignablerelays.
Bothrelaysaresetto“unused”bythefactoryunlessspecifiedotherwise
bythecustomeratthetimeoforder.TheSPDTrelaysarefullyconfigurable,seeC‐22manualforamoredetailed
description.TheRelaysmustbefirstassignedintheConfigure/TrimMenuandthenconfiguredintheStepUp
Menu.Followth
eexamplebelowforguidelinesonassigningandconfiguringtherelays.

ScreenShotsforAssigningtheAlarmRelays

#1HomeScreen
PressMenuSelect
Downbutton

#2GraphicalDisplay
PressMenuSelect
Downbutton

#3SelectionMenu
Buffer
PressMenuSelect
Downbutton

#4SelectionMenu
Setup
PressMenuSelect
Downbutton

#5SelectionMenu
Status
PressMenuSelect
Downbutton

#6Configure/TrimMenu
ToentertheConfigure
MenuSimultaneouslypress
bothHorizontalCALIBRATE
keys
#7PasswordsScreen
PressMenuSelect
Downbutton

#8DefaultDisplayScreen
PressMenuSelect
Downbutton

#94‐20AssignmentScreen
PressMenuSelect
Downbutton

#10ManualModeScreen
PressMenuSelect
Downbutton

