DisplayedvalueisLowerthan
DPDtestvalue(cont’d)
Lowtensiononthe
membrane



Flowtolowthroughtheflow
cell


Airbubblestrappedon
membrane


Airbubbleinsidethesensor
betweencathodeand
membrane

pHindicationlowerthan
actualvalue

Temperatureindication is 
higherthanactualvalue.

Verifythe
Me
asuring
Chamberisfullytightened
ontothebodyorreplace
membrane.

CleanCHFC,fittingsand
tubing,verifythesamplefeed
rateat+10gal/hr.

LoosenFCSfittingandlift
sensorslightlytopurgeair
trappedintheflowcell.

Refillsensor,seeMaintenance



CalibratepHsensororadjust
valueonun
compensatedFCA

CalibratetheTemperature
(seeCalibration)The
temperaturesensorlagsthe
processtemperaturewaitfor
temperatureequilibrium.


ZeroChlorineReading

Noelectrolyteinthesensor


OpenCircuitonFCS,broken
orbadelectricalconnection


RefillSensor


Checkconnectorandwiringto
theconnectorinsidetheC‐22

UnstableChlorineReading


Airbubblesonthemembrane



Changingtemperature,the
lagofthetemperaturesensor
lookslikedrift


LoosenFCSfittingandlift
sensorslightlytopurgeair
trappedintheflowcell.

Waitforequilibrium



