296 INCH CHIPPER
ENGLISH
Section
7 SPECIFICATIONS
*Use of medium strength thread locker required.
**If removing cap to program, cap and rubber washer must be reinstalled to correct torque to maintain IP67 seal.
DESCRIPTION ENGLISH METRIC
Overall size 126" L x 57" W x 104" H 320 x 145 x 264 cm
Overall weight 1,581 lbs. 718 kg
Max chipper capacity 6" dia. 15.2 cm dia.
Chipper blades 4 reversible (4 x 5.1 x 0.50") 4 reversible (10.2 x 13.0 x 1.3 cm)
Chipping anvil 4-edge adjustable
Rotor speed 1,650 RPM
Rotor size 26" dia. 66 cm dia.
Rotor weight 165 lbs. 75 kg
Discharge tube size 6.0" 15.3 cm
Discharge tube height 104" 2.6 m
Drive type Belt
Drive belt size Triple banded 3RB48
Tire size P215/75R15
Jack 800 lb. rating 363 kg
Engine 627cc Briggs & Stratton
Fuel tank capacity 9.5 gal. 35.9 L
Hydraulic feed rate 0-125 ft/min 0-38 m/min
Hydraulic oil tank capacity 3 gal. 11.4 L
SPECIAL TORQUE REQUIREMENTS
LOCATION HARDWARE DESCRIPTION
TORQUE
(UNIFIED INCH)
TORQUE
(METRIC)
Controller mounting hardware* 8-32 screws 20 in-lbs. 2.26 Nm
Back of controller USB seal cap** 20 oz-in. 0.14 Nm
