Echo CS-3510 User Manual

SAFETY CS-3510
18 X7503360201
© 8/20 ECHO Incorporated
Note: Not all symbols will appear on your unit.
Manual Safety Symbols and Important Information
Throughout this manual and on the product itself, you will find safety alerts
and helpful, informational messages preceded by symbols or key words.
The following is an explanation of those symbols and key words and what
they mean to you.
Choke Control “COLD
START” Position
(Choke Closed)
Choke Control “RUN”
Position (Choke Open)
Purge Pump
De-Compression
Device
STOP / Momentary
STOP Switch
Symbol Description Symbol Description
STOP
STOP

Echo CS-3510 Specifications

General

Engine Displacement	34.4 cc
Bar Length	16 in
Chain Pitch	3/8 in
Chain Gauge	0.050 in
Fuel Capacity	0.27 liters
Oil Capacity	0.2 liters
Fuel Tank Capacity	0.27 liters
Oil Tank Capacity	0.2 liters
